B-12 SPARCengine Ultra AX
i
OEM Technical Manual • May 1999
FIGURE B-13 UltraSPARC IIi Module With Pin Fin Heatsink
27.10
(1.067)
CPU heat sink:
Socket:
Stack height for two
connectors:
0.81 ± 0.025
(0.032 ± 0.001)
10.92
(0.430) Min.
CPU Thermistor
(Under Heatsink)
CPU package:
PCB thickness:
1.57 ± 0.20
(0.062 ± 0.008)
4.05 ± 0.30
(0.159 ± 0.012)
130.00
(5.118)
100.00
(3.937)
Dimensions mm, (Inch)
44.500 (1.750) Nominal
44.975 (1.771) Worst Case
