Sun Microsystems SPARCengine Ultra AXi User Manual

B-1
APPENDIX
B
Mechanical Drawings
B.1 Ultra AXi Motherboard Dimensions
FIGURE B-1 shows a rear view of the Ultra AXi motherboard with dimensions to the
IO connectors and the IO aperture referenced to the mounting hole (0.000x0.000)
used as datum in
FIGURE B-2.
FIGURE B-1 Ultra AXi Motherboard IO View
16.5 (0.65)
42.24
(1.663)
R1.8, 8X
(R0.071, 8X)
30.5 (1.20)
∅3.277, 4X
(∅0.129, 4X)∞∞
20.4 (0.804)
13.9 (0.547)
11.43 (0.450)
1.37 (0.054)
158.75
I/O APERTURE
MOTHERBOARD
MOTHERBOARD
DATUM; 0,0
(6.250)
44.45
(1.750)
3.81
(0.150)
131.9
(5.193)
232.4 (9.150)
217.4 (8.559)
49.1
(1.934)
150.5 (5.926)
133.5 (5.256)
15
(0.590)
0.00
R1.9, 2X
(R0.075, 2X)
0.7
(0.028)
8.2
(0.323)
152.5 (6.005)
Dimensions mm (inch)
214.25 (8.435)
238.6 (9.392)
285.5 (11.244)
0.00
