C-18 SPARCengine Ultra AX i OEM Technical Manual • May 1999
The machine can be configured in many combinations of DIMMS in 16MB steps.
TABLE C-4 on page C-18 shows some of the more common combinations.
TABLE C-4 DIMM Configurations
Total
Memory
10-bit Column Address 11-bit Column Address
No of
DIMMs
DIMM
Size
Case from
Table C-2
No of
DIMMs
DIMM
Size
Case from
Table C-3
32MB 4 8MB 3, 5, 6, 9, 10, 12 4 8MB 3
48MB 2
2
16MB
8MB
3, 5, 6, 9, 10, 12 2
2
16MB
8MB
3
6 8MB 7, 11, 13, 14
64MB 2 32MB 1, 2, 4, 8 2 32MB 1, 2
4 16MB 3, 5, 6, 9, 10, 12 4 16MB 3
8 8MB 15
4
2
8MB
16MB
7, 11, 13, 14
96MB 4
4
8MB
16MB
15
6 16MB 7, 11, 13, 14
4
2
8MB
32MB
7, 11, 13, 14
2
2
32MB
16MB
3, 5, 6, 9, 10, 12
128MB 4 32MB 3, 5, 6, 9, 10, 12 4 32MB 3
8 16MB 15
2
4
32MB
16MB
7, 11, 13, 14
2 64MB 1, 2, 4, 8 2 64MB 1, 2
192MB 6 32MB 7, 11, 13, 14
4
4
32MB
16MB
15
2
4
64MB
16MB
7, 11, 13, 14
2
2
64MB
32MB
3, 5, 6, 9, 10, 12 2
2
64MB
32MB
3
