Sun Microsystems SPARCengine Ultra AXi - Power On-Off Switch Header J3301; PS;2 Speaker Header J3201; Reserved (Do Not Use)J3302; TABLE A-7 PS;2 Speaker Header

A-6 SPARCengine Ultra AX i OEM Technical Manual • May 1999
A.2.5 PS/2 Speaker Header J3201
A.2.6 Power On-Off Switch Header J3301
A.2.7 Reserved (Do Not Use) J3302
TABLE A-7 PS/2 Speaker Header
Pin # Description
1 Speaker.
2 N/C.
3 N/C.
4 Speaker.
TABLE A-8 Power Enable Switch Header
Pin # Description
1 Power On-Off Signal
2 Ground.
TABLE A-9 Reserved Header
Pin # Description
1 Reserved
2 Reserved
3 Reserved
4 Reserved
