C-10 SPARCengine Ultra AX

OEM Technical Manual • May 1999

FIGURE C-7 Hooking Up the CPU Fan Power Supply Wires to the J3603 Header

Caution – Be sure pin 1 of the fan connector is connected to pin one of J3603 on the

board. Otherwise, the fan will not operate.

J3603

Edge of board

Pin1

Fan connector

Pin 1 indicator

on fan connector
