C-20 SPARCengine Ultra AX i OEM Technical Manual • May 1999
TABLE C-5 Acceptable DIMM Locations 10-bit Column Address Mode
TABLE C-6 Acceptable DIMM Locations 11-bit Column Address Mode
10-bit Column Address Mode
Pair 0
J0404, J0403
CASE 1
CASE 2
CASE 3
CASE 4
CASE 5
CASE 6
CASE 7
CASE 8
CASE 9
CASE 10
CASE 11
CASE 12
CASE 13
CASE 14
CASE 15
Pair 3
J0302, J0301
Pair 2
J0304, J0303
Pair 1
J0402, J0401
Pair 0
J0404, J0403
CASE 1
CASE 2
CASE 3
11-bit Column Address Mode
Pair 2
J0304, J0303
DO NOT USE
THESE PAIRS
