Sun Microsystems SPARCengine Ultra AXi User Manual

Appendix A Jumpers, Headers, Connectors, and Adapters A-17
163
UPA_ADDRESSBUS<13>
164
VDD
165
UPA_ADDRESSBUS<12>
166
UPA_ADDRESSBUS<11>
167
GND
168
UPA_ADDRESSBUS<10>
169
UPA_ADDRESSBUS<09>
170
VDD
171
UPA_ADDRESSBUS<08>
172
UPA_ADDRESSBUS<07>
173
GND
174
UPA_ADDRESSBUS<06>
175
UPA_ADDRESSBUS<05>
176
VDD
177
UPA_ADDRESSBUS<04>
178
UPA_ADDRESSBUS<03>
179
GND
180
UPA_ADDRESSBUS<02>
181
UPA_ADDRESSBUS<01>
182
VDD
183
UPA_ADDRESSBUS<00>
184
UPA_P_REPLY<1>
185
GND
186
UPA_ADDRESS_VALID
187
UPA_P_REPLY<0>
188
VDD
189
UPA_P_REPLY<0>
190
UPA_P_REPLY<2>
191
GND
192
UPA_S_REPLY<1>
193
FFB_INT-L
194
VDD
195
UPA_RESET_L
196
SPEED<1>
197
GND
198
SPEED<0>
199
POWER_OK
200
VCC
201
SPEED<2>
202
SPARE8
203
GND
204
SPARE9
205
SPARE10
206
VCC
207
SPARE11
208
SPARE4
209
GND
210
SPARE5
211
VCC
212
VCC
213
SPARE3
214
VCC
215
GND
216
VCC
217
VCC
218
VCC
219
VCC
TABLE A-16 UPA64S (Vertical FFB) Connector Pinouts
Pin Signal Name Pin Signal Name Pin Signal Name
1
AA
SECTION AA
1
3
2
