6. Install the top cover.
See Section 6.1, “Installing the Top Cover” on page 6-2.
7. Install the server into the rack.
See Section 6.2, “Reinstalling the Server in the Rack” on page 6-3.
8. Install the drives.
Note – Ensure you are installing the drives in the correct drive bays.
See Section 3.2.5, “Installing a Hard Drive or SSD” on page 3-7.
9. Install the DVD/USB module.
See Section 3.5.2, “Installing the DVD/USB Module” on page 3-22.
10. Reconnect the power cord (or cords) to the power supply (or supplies).
Verify that the AC Present LED is lit.
See Section 6.4, “Powering On the Server” on page 6-5.
11. Power on the server.
See Section 6.4, “Powering On the Server” on page 6-5.
5.3 Servicing the Drives Backplane
You must remove the drives backplane to service the front control panel light pipe
assemblies.
Note – FRU: This field-replaceable unit should be replaced only by qualified service
technicians. Contact your Sun Service representative for assistance.
5.3.1 Removing the Drives Backplane
1. Remove the drives cage.
See Section 5.2.1, “Removing the Drives Cage” on page 5-5.
2. Remove the four No. 2 Phillips screws securing the backplane to the drives
cage. (
FIGURE 5-5)
