Chapter 4 Servicing Motherboard Components 4-11
Note – This is a customer-replaceable unit.
Caution – Ensure that all power is removed from the server before installing
memory tray or damage to the FB-DIMMs might occur. You must disconnect all
power cables from the system before performing this procedure.
4.2.1 Removing the Memory Tray
1. Slide the system out of the rack.
See Section 2.5, “Extending the Server to the Maintenance Position” on page 2-5.
2. Remove the top cover.
See Section 2.8, “Removing the Top Cover” on page 2-11.
3. Unlock the two memory tray tabs by pressing away from the memory tray, as
shown in
FIGURE 4-6. [1]
4. Grab the handles towards the center of the memory tray [2], and lift the memory
tray up [3].
5. Set the memory tray aside.
