A-1
APPENDIX
A
Connector Pinouts
This appendix provides reference information about the system back panel ports and
pin assignments.
Topics covered in this appendix include:
■ Section A.1, “Serial Management Port Connector” on page A-2
■ Section A.2, “Network Management Port Connector” on page A-3
■ Section A.3, “Video Connector” on page A-4
■ Section A.4, “USB Connectors” on page A-5
■ Section A.5, “Gigabit Ethernet Connectors” on page A-6
FIGURE A-1 Sun Fire X4450 Back Panel
