C-2 Sun Fire X4450 Server Service Manual • November 2009
2. Highlight the field to be modified using the arrow and Tab keys.
Use the left and right arrow keys to move sequentially back and forth through the
menu screens. Fields that can be reconfigured are displayed in color. All other
fields are nonconfigurable.
■ Use the up and down arrows, on the keyboard, to scroll through a menu.
■ Use the Tab key to move back and forth across columns.
3. Press Enter to select the field.
A dialog box shows the available options.
4. Modify the setup field and close the screen.
5. If you need to modify other setup parameters, use the arrow and Tab keys to
navigate to the desired screen and menu item, and then repeat Step 1 through
Step 4. Otherwise, go to Step 6.
6. Press and release the right arrow key until the Exit menu screen appears.
7. Follow the instructions on the Exit menu screen to save your changes and exit the
Setup utility.
C.1.2 BIOS Setup Screens Overview
TABLE C-1 contains summary descriptions of the top-level BIOS setup screens.
TABLE C-1 BIOS Setup Screens Summary
Screen Description See...
Main General product information, including
BIOS type, processor, memory, and
time/date.
Section C.2.1, “BIOS Main
Menu Screens” on page C-4
Advanced Configuration information for the CPU,
memory, IDE, Super IO, trusted computing,
USB, PCI, MPS and other information.
Section C.2.2, “BIOS
Advanced Menu Screens” on
page C-6
Boot Configure the boot device priority (drives
and the DVD-ROM drive).
Section C.2.3, “BIOS Boot
Menu Screens” on page C-11
Server Server devices can be configured by the
BIOS (if applicable).
Section C.2.4, “BIOS Server
Menu Screens” on page C-14
Security Set or change the user and supervisor
passwords.
Section C.2.5, “BIOS Security
Menu Screens” on page C-18
Exit Save changes and exit, discard changes and
exit, discard changes, or load optimal or
failsafe defaults.
Section C.2.6, “BIOS Exit
Menu Screens” on page C-19
