4-1
CHAPTER
4
Servicing Motherboard Components
This chapter describes how to replace the motherboard and its components in the
Sun Fire X4450 server.
Note – Before performing any of the procedures in this chapter, perform the
procedures described in Chapter 2, Preparing to Service the System.
The following topics are covered in this chapter:
■ Section 4.1, “Servicing FB-DIMMs” on page 4-2 (CRU)
■ Section 4.2, “Servicing the Memory Tray” on page 4-11 (CRU)
■ Section 4.3, “Replacing the Memory Riser” on page 4-14 (CRU)
■ Section 4.4, “Servicing the Air Duct” on page 4-16 (CRU)
■ Section 4.5, “Servicing PCIe Risers” on page 4-20 (CRU)
■ Section 4.6, “Servicing PCIe Cards” on page 4-22 (CRU)
■ Section 4.7, “Servicing the Battery” on page 4-28 (CRU)
■ Section 4.8, “Servicing the Motherboard Assembly” on page 4-29 (FRU)
■ Section 4.9, “Servicing CPUs” on page 4-35 (FRU)
■ Section 4.10, “Resetting Passwords and Clearing CMOS NVRAM” on page 4-43
■ Section 4.11, “Recovering from Corrupt Service Processor Software” on page 4-46
Caution – Never attempt to run the server with the covers removed. There is
hazardous voltage present.
Caution – Equipment damage possible. The covers must be in place for proper air
flow.
