Chapter 1 Sun Fire X4450 Server Overview 1-5
FIGURE 1-1 Cables
1.2.3 Dimensions
The 2U chassis form factor dimensions are listed in TABLE 1-3.
Figure Leg end
1 Drive data cables
2 Motherboard to PDB cable
3 Top cover interlock cable
4 PSU backplane interconnect cable
TABLE 1-3 Sun Fire X4450 Server Dimensions
Dimension Sun Fire X4450
Height 87.85 mm/3.46 inches
Width 445.71 mm/17.55 inches (includes ears - chassis is 16.75 mm/425.46 inches)
Depth 733.65 mm/28.88 inches (includes PSU handle - chassis is 28.00/711.25)
Weight Maximum: 25.6 kg/56.3 lbs.
