2-8 Sun Fire X4450 Server Service Manual • November 2009
FIGURE 2-4 Metal Lever and Cable Management Arm
Caution – If necessary, use two people to dismount and carry the
chassis.
4. From the front of the server, pull the release tabs forward and pull the server
forward until it is free of the rack rails (
FIGURE 2-5).
A release tab is located on each rail.
