SUNSTONE CDDP-A - Modbus Data Structures; Modbus Register Types and Assignments

Questions? Call or Text +1-801-658-0015 • 61
e Micro Welder Experts
Funtion
Code (dec)
Funtion
Code (hex)
Name Read/Write
103 0x67 General Info Read
104 0x68 Previous Weld Results Read
105 0x69 Alarm States Read
106 0x6A Waveform Report General Read
107 0x6B Emergency Stop State Read
108 0x6C Basic PLC States Read
109 0x6D RSS States Read
110 0x6E Network info Read
DATA STRUCTURES
Data Structures Size Count Type
Coil 1-Bit 23 Read/Write
Discrete Input 1-Bit 25 Read
Holding Register 16-Bit 33 Read/Write
Input Register 16-bit 82 Read
File Record 4 Read
COILS
Index (dec) Index (hex) Coil
0 0x0000 Pulse 1 Power Comparator Enable
1 0x0001 Pulse 2 Power Comparator Enable
2 0x0002 Pulse 1 Current Comparator Enable
3 0x0003 Pulse 2 Current Comparator Enable
4 0x0004 Pulse 1 Voltage Comparator Enable
5 0x0005 Pulse 1 Voltage Comparator Enable
6 0x0006 Pluse 1 Enable
7 0x0007 Pulse 2 Enable
8 0x0008 Comparator Action after Pulse 1
9 0x0009 Roll Spot Enabled
10 0x000A Alarm - Temperature Enable
11 0x000B Alarm - Comparator Enable
12 0x000C Alarm - Part Check Enable
