SUNSTONE CDDP-A USERS GUIDE
FILE RECORDS: RESPONSE TO “FIRST 4 TIME VALUES”
Data Type Data Size Data Output Data Value
Server Address 1 Byte 0xFF
Function Code 1 Byte 0x14
Response Length 1 Byte 0x0A
Request Length 1 Byte 0x09
Reference Type 1 Byte 0x06
File Record 1 - Data [0] 2 Byte 0x0009 0.45ms (9 x 0.05)
File Record 1 - Data [1] 2 Byte 0x000C 0.6ms
File Record 1 - Data [2] 2 Byte 0x000F 0.75ms
File Record 1 - Data [3] 2 Byte 0x0011 0.85ms
FILE RECORDS: READ FIRST 4 TIME VALUES AND FIRST 4 VOLTAGE VALUES
Data Type Data Size Data Input
Server Address 1 Byte 0xFF
Function Code 1 Byte 0x14
Byte Count 1 Byte 0x0E
Sub Request 1: Reference Type 1 Byte 0x06
Sub Request 1: File Number 2 Byte 0x0001
Sub Request 1: Record Number 2 Byte 0x0000
Sub Request 1: Record Length 2 Byte 0x0004
Sub Request 2: Reference Type 1 Byte 0x06
Sub Request 2: File Number 2 Byte 0x0002
Sub Request 2: Record Number 2 Byte 0x0000
Sub Request 2: Record Length 2 Byte 0x0004
