Byte 16 17 18 19 20 21 22 23
Name Capacitor Voltage
(mV)[1:0]
Terminal Voltage (mV) Terminal Current (A)
[3:2]
Type uint32 uint32 uint32
Byte 24 25 26 27 28 29 30 31
Name Terminal Current (A)
[1:0]
Weld Task
Current
State
Charge
Task Cur-
rent State
Weld On
State
Charge
is Good
Enough
for Weld
PLC Set to
Lock
PLC Input
Reset
Weld
Count
Type uint32 Weld Task
State
Charge
Task State
bool bool Lock
State
bool
CUSTOM FUNCTIONS: GENERAL INFO: WELD TASK STATES
Weld Task
State (hex) Name
0x0000 Invalid
0x0001 Idle
0x0002 Pre-Weld
0x0003 Weld Head On
0x0004 Squeeze Delay
0x0005 Welder Overheated
0x0006 Part Check
0x0007 Weld P1
0x0008 In-between Pulses
0x0009 Weld P2
0x000A Reporting
0x000B Hold Delay
0x000C Weld Head O
0x000D Roll Spot - In-between Welds
0x000E Roll Spot - Waiting on Charge
0x000F Finalize
