Byte 0 1 2 3 4 5
Name PLC Pin 3 PLC Pin 4 PLC Pin 5 PLC Pin 6 PLC Pin 7 PLC Pin 8
Type PLC Input
Assign-
ment
PLC Input
Assign-
ment
PLC Out-
put As-
signment
(Constant)
PLC Out-
put As-
signment
(Constant)
PLC
Output
Assign-
ment
PLC
Output
Assign-
ment
Refer to “PLC Output Pin Assignment” and “PLC Input Pin Assignment”

Byte 0 1 2 3 4 5 7 8
Name Weld Count Comparator Fail Count
Type uint32 uint32

Byte 0
Name RSS Mode
Type uint8

Byte 0 1 2 3 4 5 7 8
Name Charge Temperature Weld Temperature Bleed Temperature Primary
Trigger
State
Second-
ary 5 Din
Trigger
State
Type uint16 uint16 uint16 bool bool
Byte 8 9 10 11 12 13 14 15
Name Second-
ary 3 Din
Trigger
State
Weld
Head Trig-
ger State
Analog Foot Pedal Voltage Capacitor Voltage
(mV)[3:2]
Type bool bool uint32 uint32
