SUNSTONE CDDP-A - Basic PLC States (3 X 16 Bit Registers); RSS States (1 X 8 Bit Coil); Network Info (20 X 16 Bit Registers)

80 • Questions? Call or Text +1-801-658-0015
SUNSTONE CDDP-A USERS GUIDE

Byte 0 1 2 3 4 5
Name PLC Pin 3
- State
PLC Pin 4
- State
PLC Pin 5
- State
PLC Pin 6
- State
PLC Pin 7
- State
PLC Pin 8
- State
Type bool bool bool bool bool bool

Byte 0
Name Current
RSS Value
Type uint8

Byte 0 1 2 3 4 5 6 7
Name IP[3] IP[2] IP[1] IP[0] Subnet
Mask[3]
Subnet
Mask[2]
Subnet
Mask[1]
Subnet
Mask[0]
Type uint8 uint8 uint8 uint8 uint8 uint8 uint8 uint8
Byte 8 9 10 11 12 13 14 15
Name
Gateway[3] Gateway[2]
Gate-
way[1]
Gate-
way[0]
Alterna-
tive Port
Priority IP
1[3]
Priority IP
1[2]
Type uint8 uint8 uint8 uint8 uint16 uint8 uint8
