FILE RECORDS: RESPONSE TO “FIRST 4 TIME VALUES AND FIRST 4 VOLTAGE VALUES”
Data Type Data Size Data Output Data Value
Server Address 1 Byte 0xFF
Function Code 1 Byte 0x14
Response Length 1 Byte 0x14
Sub Request 1: Request Length 1 Byte 0x09
Sub Request 1: Reference Type 1 Byte 0x06
Sub Request 1: File Record 1 - Data [0] 2 Byte 0x0009 0.45ms (9 x 0.05)
Sub Request 1: File Record 1 - Data [1] 2 Byte 0x000C 0.6ms
Sub Request 1: File Record 1 - Data [2] 2 Byte 0x000F 0.75ms
Sub Request 1: File Record 1 - Data [3] 2 Byte 0x0011 0.85ms
Sub Request 2: Request Length 1 Byte 0x09
Sub Request 2: Reference Type 1 Byte 0x06
Sub Request 2: File Record 2 - Data [0] 2 Byte 0x0000 0mV
Sub Request 2: File Record 2 - Data [1] 2 Byte 0x0614 1,556mV=1.556V
Sub Request 2: File Record 2 - Data [2] 2 Byte 0x1AF3 6,899mV=6.899V
Sub Request 2: File Record 2 - Data [3] 2 Byte 0x1C45 7,237mV=7.237V
