SUNSTONE CDDP-A USERS GUIDE
Index (dec) Index (hex) Coil
13 0x000D Alarm - Electrode Stuck Enable
14 0x000E Alarm - Weld Counter Enable
15 0x000F Alarm - Trigger Enable
16 0x0010 Alarm - Wrong Trigger Enable
17 0x0011 Alarm - Invalid Selection Enable
18 0x0012 Warning - Temperature Enable
19 0x0013 Warning - Comparator Enable
20 0x0014 Warning - Weld Counter Enable
21 0x0015 Weld Triggered
22 0x0016 Modbus E-Stop
DISCRETE INPUTS
Index Discrete Input Note
0
PLC Pin 3 - State
Active Low
1
PLC Pin 4 - State
Active Low
2
PLC Pin 5 - State
Active Low
3
PLC Pin 6 - State
Active Low
4
PLC Pin 7 - State
Active Low
5
PLC Pin 8 - State
Active Low
6
Error - Heartbeat
7
Error - Overtemp
8
Error - Terminal Voltage
9
Error - Capacitors Overvoltage
10
Error - Capacitors not Charging
11
Alarm - Temperature State
12
Alarm - Comparator Failures in a Row State
13
Alarm - Electrode Stuck State
14
Alarm - Weld Counter Preset Limit State
15
Alarm - Remote Schedule Selection Invalid State
16
Alarm - Trigger in no Weld State State
17
Alarm - Wrong Trigger Detected State
18
Alarm - Part Check Failed State
19
Warning - Comparator Failures in a Row State
20
Warning - Temperature State
21
Warning - Weld Counter Preset Limit State
22
Previous Weld Results P1 Enabled
