CUSTOM FUNCTIONS: GENERAL INFO: CHARGE TASK STATES
Charge Task
State (hex) Name
0x0000 Invalid
0x0001 Charged
0x0002 Charging
0x0003 Draining
0x0004 Drained
CUSTOM FUNCTIONS: GENERAL INFO: LOCK STATES
Charge Task
State (hex) Name
0x0000 Unlocked
0x0001 Locked
0x0002 Lock Disabled

Byte 0 1 2 3 4 5 6 7
Name Roll Spot
Enabled
Part
Check
Passed
Compara-
tor - Re-
sult
Compara-
tor - Pulse
1 - Power
- Result
Compara-
tor - Pulse
2 - Power
- Result
Compara-
tor - Pulse
1 - Current
- Result
Compara-
tor - Pulse
2 - Current
- Result
Compara-
tor - Pulse
1 - Voltage
- Result
Type bool bool
Comparator
Result
Comparator
Result
Comparator
Result
Comparator
Result
Comparator
Result
Comparator
Result
Byte 8 9 10 11 12 13 14 15
Name
Compara-
tor - Pulse
2 - Voltage
- Result
Pulse 1
Enabled
Pulse 2
Enabled
Pulse 1 Peak Current (A) Pulse 2
Peak Cur-
rent (A)[3]
Type
Comparator
Result
bool bool uint32 uint32
Byte 16 17 18 19 20 21 22 23
Name Pulse 2 Peak Current (A)[2:0] Pulse 1 Peak Voltage (mV)
Pulse 2
Peak Volt-
age (mV)[3]
Type uint32 uint32 uint32
