5-9 FUEL SYSTEM
INSPECTION
NOTE:
If cracks, excessive wear or other damage is found on any com-
ponent, replace component.
Needle valve / Valve seat
Check needle valve and valve seat.
If grooved or damaged, replace valve and seat.
If dirt is found, clean.
Remove screw and pump bracket 0.
Remove high pressure fuel pump A from separator cover and
then disconnect pump lead wire connector.
Float
Check float.
If cracked or damaged, replace float.
To Next Page
