POWER UNIT 6-24
DISASSEMBLY
1. Remove tappets with shims.
2. Using valve lifter and attachment, remove valve cotters 1
while compressing valve spring.
09916-14510 : Valve lifter
09916-14910 : Attachment
09916-84511 : Tweezers
3. Remove valve spring retainer 2, valve spring 3 and valve
4.
4. Remove valve stem seal 5 and valve spring seat 6.
NOTE:
Reassemble each valve and valve spring in their original posi-
tions.
z
z
z
z
z
1
1
2
3
5
64
1
5
6
z
