3-47 ENGINE CONTROL SYSTEM
REMOVAL / INSTALLATION
FLYWHEEL / CKP SENSOR / CMP SENSOR
1 Flywheel bolt
2 Washer
3 Key
4 Flywheel
5 CKP sensor
6 Screw
7 CMP sensor
8 Bolt
1
2
3
4
5
5
5
6
7
8
NOTE:
Clean flywheel and crankshaft mating
surfaces with cleaning solvent.
Crankshaft
@ 200 N
.
m
(20.0 kg-m, 145 lb.-ft.)
o
h
