14 DF40/50 “K6” (’06) MODEL
ECM
The ECM has been changed in program.
FUEL FILTER
A new style fuel filter will be used that provides a drain feature.
This new filter requires several new components shown below and a new mounting bracket to retain the fil-
ter onto the outboard.
Inspect the fuel filter regularly.
If any water and impurities exists in the fuel filter, remove the drain cap and drain the water and impurities.
IAC HOSE
The inhalation location of air of IAC was changed from silencer case to atmospherer.
The IAC hose has been changed in length and routing.
The silencer cap, IAC hose clamp, hose clamp and clamp bolt have also been added.
Fuel filter bracket
Fuel filter
Fuel filter
Clip
Drain cap
Fuel fiter clamp
Fuel filter bracket
IAC hose
IAC valve silencer
IAC hose
IAC valve silencer
Silencer cap
