LOWER UNIT 9-10
DRIVESHAFT BEARING HOUSING
• Inspect housing. Replace if cracked or damaged.
• Inspect bearing. Replace if pitted, noisy or rough.
• Check condition of oil seals. Replace if nicked, cut or worn.
Replacing driveshaft oil seal
1. Using bearing remover, draw the driveshaft bearing out of
the driveshaft housing.
09923-74510 : Bearing remover
2. With the oil seal remover, draw the two oil seals out of the
driveshaft bearing housing.
09913-50121 : Oil seal remover
3. Apply Water Resistant Grease to the inner circumference of
the driveshaft bearing housing.
99000-25160 : Water Resistant Grease
4. Grease the inner lips of the seal.
With the lips facing away from driveshaft bearing, place seal
in position and drive it into the bearing housing.
5. Place the driveshaft bearing in position and drive it into the
bearing housing.
l
z
z
Direction of
water pump case
