Suzuki DF 40 User Manual

LOWER UNIT
CONTENTS
REMOVAL & DISASSEMBLY ________________________________ 9-1
PINION BEARING _________________________________________ 9-5
INSPECTION _____________________________________________ 9-7
PROPELLER.................................................................................................... 9-7
GEARCASE ..................................................................................................... 9-7
GEAR ............................................................................................................... 9-8
PROPELLER SHAFT COMPONENTS ........................................................... 9-8
PROPELLER SHAFT BEARING HOUSING .................................................. 9-8
SHIFT ROD AND SHIFT CAM ........................................................................ 9-9
WATER PUMP AND RELATED ITEMS .......................................................... 9-9
DRIVESHAFT BEARING HOUSING .............................................................. 9-10
DRIVESHAFT .................................................................................................. 9-11
ASSEMBLY & INSTALLATION _______________________________ 9-12
TRIM TAB ________________________________________________ 9-22
LOWER UNIT GEARS-SHIMMING AND ADJUSTMENT ___________ 9-23
9

Suzuki DF 40 Specifications

General

Displacement	941 cc
Starting System	Electric
No. of Cylinders	3
Steering	Remote
Gear Ratio	2.27:1
Alternator Output	12V 19A
Engine Type	4-Stroke, DOHC
Maximum Output	40 hp
Fuel System	Multi-Point Sequential Electronic Fuel Injection
Shaft Length	S: 381 mm, L: 508 mm
Oil Capacity	2.7 L
