3-29 ENGINE CONTROL SYSTEM
FAIL-SAFE SYSTEM
The fail-safe system is closely related to the self-diagnostic system.
When an abnormality occurs in a sensor signal, the ECM ignores the out-of-range signal and assumes a pre-
programmed value for the failed sensors.
This allows the engine to continue running under the fail-safe condition.
PRE-PROGRAMMED VALUE FOR FAIL-SAFE SYSTEM
NOTE:
There is no back-up system for the ECM itself. The engine will stop if it has failed.
MAP sensor 1 • 319 – 475 mmHg / (750 – 4000 r/min)
CMP sensor • Fuel Injection:
1 simultaneous injection for all cylinders per 2 crankshaft rotations
• Ignition Timing:
Normal ignition timing based on signals from CKP sensor (s)
Cylinder temp. sensor 60 °C (140 °F)
IAT sensor 45 °C (113 °F)
Exhaust manifold
60 °C (140 °F)
temp. sensor
FAILED ITEM PRE-PROGRAMMED VALUE
