8-15 POWER TRIM AND TILT
Apply Water Resistant Grease to the PTT rod upper shaft 4,
then insert the shaft through the swivel bracket and tilt rod.
99000-25160 : Water Resistant Grease
Secure the upper shaft with the snap ring 5.
Route the PTT motor cable in through the lower cover and con-
nect the terminals to the PTT relays.
(Cable routing–see the WIRE / HOSE ROUTING section on
page 10-2 to 10-6.)
l
To Next Page
