LOWER UNIT 9-2
Loosen the four(4) nuts 1, then remove the water pump case
2, impeller 3, and pump under plate 4.
Keep the impeller key 5 for reuse and discard the plate gas-
ket.
Remove the two (2) bolts 1 securing the propeller shaft bear-
ing housing to the gearcase.
Using special tools, draw out the propeller shaft bearing hous-
ing.
Remove the propeller shaft and bearing housing assembly.
09930-30102 : A Sliding hammer
09930-30161 : B Propeller shaft remover
Hold the pinion nut securely, then fit special tool to the driveshaft
and loosen the pinion nut.
09921-29510 : Driveshaft holder
z
z
A
B
z
z
