POWER UNIT 6-7
17. Loosen screw A and disconnect lead wire from oil pres-
sure switch.
18. Remove two bolts
B and front panel C.
19. Disconnect water inlet hose D and water outlet hose E
from crankcase.
20. Remove cotter pin
F and washer G, then separate clutch
lever link
H from clutch shaft arm I.
21. Remove E-ring
J, clutch control lever K and clutch
shaft arm
I.
22. Remove two bolts
M and clutch lever holder L.
23. Disconnect neutral switch lead wire connector
N.

Suzuki DF 90 Specifications

General

Steering	Remote
Starting System	Electric
Number of Cylinders	4
Trim Method	Power Trim and Tilt
Full Throttle Operating Range	5, 500 - 6, 300 rpm
Fuel System	Multi-point sequential electronic fuel injection
Ignition System	Fully-transistorized
Exhaust	Through Prop Hub Exhaust
Shaft Length	508 mm (20 in), 635 mm (25 in)
Fuel Type	Unleaded gasoline (87 octane or higher)
