9-12 LOWER UNIT
DRIVESHAFT
• Inspect driveshaft / splines for wear, twist or other damage.
Replace if necessary.
• Inspect driveshaft bearing for pitting, rough or other damage.
Replace if necessary.
DRIVESHAFT OIL SEAL HOUSING
• Inspect housing for cracks or other damage. Replace if nec-
essary.
• Inspect oil seals and O-ring for wear, cuts, nicks or tears.
Replacing driveshaft oil seal
1. Extract oil seals using oil seal remover.
\ 09913-50121 : Oil seal remover
2. Apply Water Resistant Grease to inner circumference of
housing.
N 99000-25161 : Water Resistant Grease
3. Using an oil seal installer, drive two oil seals (one at a time)
into housing.
The lipped portion of seal should face towards water pump
case.
Grease inner lips of seal.
Direction of
water pump case
To Next Page
