DF90/115/140 “K8” (’08) MODEL
18-23
DIGITAL GAUGE SYSTEM
DIGITAL GAUGE
The digital gauge and the components required for installing the digital gauge are available as optional com-
ponents.
The new gauge system components are as follows.
NOTE 1:
• Tachometer (P/no. 34200-98J00, 34200-98J10) and interface module (P/no. 34922-98J00) for DF300 can
not be used.
• Conversely, New tachometer (P/no. 34200-98J01, 34200-98J11) and interface module (P/no. 34922-
98J01) can be used for DF300.
NOTE 2:
• Requires commercially available NMEA 2000 transducer with speed input.
Refer
No.
Part name Part No. Remarks
—
Speedometer assy. [NOTE 2] 34100-98J00 Max. 130 KM/H (Black)
Speedometer assy. [NOTE 2] 34100-98J10 Max. 130 KM/H (White)
Speedometer assy. [NOTE 2] 34100-98J20 Max. 80 KM/H (Black)
Speedometer assy. [NOTE 2] 34100-98J30 Max. 80 KM/H (White)
—
Tachometer assy. [NOTE 1] 34200-98J01 Black
Tachometer assy. [NOTE 1] 34200-98J11 White
—
Fuel gauge assy. 34300-98J00 Black
Fuel gauge assy. 34300-98J10 White
—
Voltage meter assy. 34600-98J00 Black
Voltage meter assy. 34600-98J10 White
—
Trim meter assy. 34800-98J00 Black
Trim meter assy. 34800-98J10 White
— Active hub 34921-98J00
— Passive hub 34921-98J10 Multiple engine
— Interface module [NOTE 1] 34922-98J01
1 Adaptor, Interface module harness 36661-93J00
2 Interface harness assy. 36661-98J00
—
Hub harness (1 M) 36662-98J00
Dual stations
Hub harness (6.5 M) 36662-98J10
3
Active hub power harness (2.5 M) 36663-98J00
Active hub power harness (6 M) 36663-98J10
4 3” gauge harness assy. 36664-98J00
5 2” gauge harness assy. 36664-98J10
6 Jumper wire 36665-98J00
— 8 pin connector cap 36666-98J00
In case of one piece of 3
inch gauge.
7 6 pin connector cap 36666-98J10
— 2 pin connector cap 36667-98J00 Dual stations
