14-4
DF90/115/140 “K4” (’04) MODEL
*SPECIFICATIONS (
DF140T/140WT/140Z
)
* These specifications are subject to change without notice.
DIMENSIONS & WEIGHT
PERFORMANCE
POWERHEAD
Item Unit
Data
DF140(W)T DF140Z
PRE-FIX 14001F 14001Z
Overall length (front to back) mm (in) 779 (30.7)
Overall width (side to side) mm (in) 481 (18.9)
Overall height
L mm (in) 1611 (63.4)
UL mm (in) 1738 (68.4)
Weight
(without engine oil)
L kg (lbs) 186.0 (410)
UL kg (lbs) 191.0 (421)
Transom height
L mm (inch type) 539 (20)
UL mm (inch type) 666 (25)
Maximum output kW (PS) 103 (140)
Recommended operating range r/min 5 600 – 6 200
Idle speed r/min 700 ± 50 (in-gear: approx. 700)
Engine type 4-stroke DOHC
Number of cylinders 4
Bore mm (in) 86 (3.39)
Stroke mm (in) 88 (3.46)
Total displacement
cm
3
(cu in)
2044 (124.6)
Compression ratio : 1 9.7
Spark plug NGK BKR6E
Ignition system Full-transistorized ignition
Fuel supply system Multi-point sequential electronic fuel injection
Exhaust system Through prop exhaust
Cooling system Water cooled
Lubrication system Wet sump by trochoid pump
Starting system Electric
Throttle control Remote control
