Suzuki DF 90 - Df90;115;140 K8 (2008) Model

DF90/115/140 “K8” (’08) MODEL 18-1
CONTENTS
DF90/115/140 “K8” (2008) MODEL
SPECIFICATIONS (DF90T/115T/115WT) ....................................... 18-2
SPECIFICATIONS (DF140T/140WT/140Z/140WZ) ......................... 18-4
SERVICE DATA (DF90T/115T/115WT) ........................................... 18-6
SERVICE DATA (DF140T/140WT/140Z/140WZ) ............................ 18-13
PERIODIC MAINTENANCE ............................................................. 18-20
IDLE SPEED ............................................................................. 18-20
ENGINE CONTROL SYSTEM ......................................................... 18-22
ECM ........................................................................................... 18-22
WIRING HARNESS ................................................................... 18-22
DIGITAL GAUGE SYSTEM ............................................................. 18-23
DIGITAL GAUGE ...................................................................... 18-23
MODIFICATION OF HARNESS CONNECTION ....................... 18-24
DIGITAL GAUGE AND RELATED PARTS CONNECTION ..... 18-24
SET-UP OF TACHOMETER ..................................................... 18-26
TACHOMETER-MONITOR ....................................................... 18-27
TACHOMETER DISPLAY INDICATION ................................... 18-28
ENGINE HOLDER ............................................................................ 18-29
WIRING DIAGRAM .......................................................................... 18-30
WIRE ROUTING ............................................................................... 18-31
