8-18 POWER TRIM AND TILT
PTT SWITCH
Test continuity between switch lead wires at each of three switch
positions.
\ 09930-99320 : Digital tester
T Tester range :
@@
@@
@(Continuity)
Tester probe connection
Continuity
Red
++
++
+ Black
--
--
-
“DN” side
depressed
Pink
Gray
(White / Red)
Yes
“UP” side
depressed
Light Blue
Yes
not
depressed
Pink
No
Gray
(White / Red)
Gray
(White / Red)
Light Blue
LBI
Gr
P
P
(W/R)
Lbl
