DF90/115/140 “K4” (’04) MODEL
14-23
PORT CLAMP BRACKET
The hole in the port clamp bracket has been enlarged.
DRIVESHAFT
The driveshaft has been changed in shape.
In accordance with this change, the washers pre-loading to driveshaft have been eliminated.
NOTE:
In accordance with this change, the servicing procedure for “Back-up Shim Adjustment” has been changed.
PINION GEAR BACK UP SHIM
The pinion gear back-up shim has been added.
Available thickness: 0.50 mm, 0.55 mm
Early Late
25 mm
17 mm × 25 mm
Washers
Flange ( 40 mm)
Early Late
To Next Page
