Suzuki DF 90 - Propeller Shaft and Connector Pin; Forward Gear and Clutch Dog

DF90/115/140 “K6” (’06) MODEL 16-35
PROPELLER SHAFT AND CONNECTOR PIN
The propeller shaft having an additional detent function.
FORWARD GEAR AND CLUTCH DOG
The forward gear and clutch dog shifter have been changed in engage angle from 5° to 2.5°.
Connector pin
Detent No.1 ball
Detent spring
Detent No.2 ball
Forward gear
Clutch dog shifter
Clutch dog angle
5˚ 2.5˚
