12-18 DF90/115 “K2” (’02) MODEL
TAPPET SHIM
New size tappet shims have been added.
I.D. number Thickness (mm)
303 3.025
305 3.050
308 3.075
310 3.100
313 3.125
The shape of camshafts has been changed from the middle of 2002 year model.
And each camshaft has own identification mark.
ENGINE HOLDER GASKET
When installing the engine holder gasket, apply Suzuki Bond “1207B” as shown in figure.
D 99000-31140 (Except for U.S. market) Suzuki Bond “1207B”
99104-33140 (Only for U.S. market)
