15-24
DF90/115/140 “K5” (’05) MODEL
TILT LIMIT SWITCH COVER
The cover has been added on the tilt limit switch.
In accordance with this change, the tilt limit switch holder bolts have been changed in length and shape as
indicated below.
PISTON OIL RING (For DF140)
The side rails of the piston oil ring have been changed in shape
and material.
TENSIONER ADJUSTER
The turn stopper plate of the tensioner adjuster has been eliminated.
15 mm
20 mm
18 mm
25 mm
Tilt limit switch cover
2.8 2.5 mm
0.5 0.45 mm
0.5 0.45 mm
Turn stopper plate
