Suzuki DF 90 - Water Hose Routing

DF90/115/140 “K3” (‘03) MODEL 13-31
Water hose
(Fuel return pipe to
Water return pipe)
Pilot water tube
Water return hose
Water return hose
White paint mark
Thermostat cover
Water return pipe (Engine holder)
WATER HOSE ROUTING
