10-6 WIRE / HOSE ROUTING
Fuel injector
High pressure fuel pump (Vapor separator)
Oil pressure switch
MAP sensor: When installing sensor, apply engine oil to sensor o-ring.
CTP switch
IAC valve
Battery charge coil screw
Battery charge coil
Cylinder temp. sensor When installing sensor, apply water resistant grease to sensor o-ring.
CMP sensor
