Suzuki RM 250 2003 - Removal; Cylinder Head; Cylinder

CYLINDER, CYLINDER HEAD AND PISTON 4-3
REMOVAL
CYLINDER HEAD
• Drain engine coolant. (!2-12)
• Remove the seat and fuel tank. (!3-2)
• Disconnect the radiator hose
1.
• Disconnect the spark plug cap
2 and remove the spark plug
3.
• Remove the engine mounting brackets
4.
• Remove the cylinder head.
NOTE:
Loosen the cylinder head nuts diagonally to prevent cylinder
head distortion.
CYLINDER
• Remove the carburetor. (!9-10)
• Remove the exhaust pipe. (!3-2)
• Remove the cylinder head O-rings
1 and 2.
• Remove the exhaust side valve cover
3.
