KICK STARTER 6-5
• Install the clutch. (!5-7)
• Fit a new gasket and install the crankcase cover.
# Crankcase cover bolt: 11 N·m (1.1 kgf-m, 8.0 lb-ft)
• Install the kick starter lever with the punched mark on the
lever aligned with the punched mark on the kick starter shaft.
# Kick starter lever bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
• Install the rear brake pedal. (!3-6)
INSPECTION AFTER REASSEMBLY
After reinstalling the kick starter assembly, inspect the follow-
ings.
• Transmission oil level (!2-9)
• Engine coolant level (!2-11)
