Suzuki RM 250 2003 - Removal; Clutch Plate

CLUTCH 5-3
REMOVAL
CLUTCH PLATE
• Drain transmission oil. (!2-9)
• Remove the rear brake pedal. (!3-3)
• Remove the clutch cover
1.
• Loosen and remove the bolts diagonally.
• Remove the clutch springs.
• Remove the pressure plate
2.
• Remove the bearing
3, push piece 4 and push rod 5.
• Remove the drive plates and driven plates.
