8G-4 IMMOBILIZER CONTROL SYSTEM
Special Tools
09931-76011 09931-76030
Tech 1A kit (SUZUKI scan
tool) (See NOTE “A”.)
Mass storage cartridge for
Te c h 1 A
16/14 pin DLC adapter for
Te c h 1 A
Tech 2 kit (SUZUKI scan tool)
(See NOTE “B”.)
NOTE:
• “A” : This kit includes the following items and substitutes for the Tech 2 kit.
1. Storage case, 2. Operator’s manual, 3. Tech 1A, 4. DLC cable (14/26 pin, 09931-76040), 5. Test
lead/probe, 6. Power source cable, 7. DLC cable adaptor, 8. Self-test adaptor
• “B” : This kit includes the following items and substitutes for the Tech 1A kit.
1. Tech 2, 2. PCMCIA card, 2. DLC cable, 4. SAE 16/19 adapter, 5. Cigarette cable, 6. DLC loopback
adapter, 7. Battery power cable, 8. RS232 cable, 9. RS232 adapter, 10. RS232 loopback connector,
11. Storage case, 12. Power supply
