AUTOMATIC TRANSMISSION (4 A/T) 7B-11
Automatic gear shift diagram
Automatic shift schedule as a result of shift control is shown below.
Gear Shift Diagram
TCC Lock-up Diagram
Shift
Throttle opening 1→22→33→44→33→22→1
Full throttle (km/h) 44 98 – 123 78 34
Closed throttle (km/h) 13 24 43 34 9 9
