Suzuki Wagon R RB310 - Diagnostic Trouble Code (DTC) Table

5E-20 ANTILOCK BRAKE SYSTEM (ABS)
Diagnostic Trouble Code (DTC) Table
CAUTION:
Be sure to perform “ABS DIAGNOSTIC FLOW TABLE” before starting diagnosis.
DTC
(displayed on SUZUKI scan tool)
DIAGNOSTIC ITEMS
NO DTC Normal
C1013 ABS control module
C1015 G sensor circuit
C1021 RF
Wheel speed sensor circuit
C1025 LF
C1031 RR
C1035 LR
C1022 RF
Wheel speed sensor circuit or sensor ring
C1026 LF
C1032 RR
C1036 LR
C1041
RF
Inlet solenoid valve circuit
C1042 Outlet solenoid valve circuit
C1045
LF
Inlet solenoid valve circuit
C1046 Outlet solenoid valve circuit
C1051
RR
Inlet solenoid valve circuit
C1052 Outlet solenoid valve circuit
C1055
LR
Inlet solenoid valve circuit
C1056 Outlet solenoid valve circuit
C1057 Power source
C1061 ABS pump motor and/or motor relay circuit
C1063 Fail safe-relay
C1071 ABS control module
