5E-18 ANTILOCK BRAKE SYSTEM (ABS)
Serial Data Link Circuit Check
CAUTION:
Be sure to perform “SYSTEM CHECK FLOW TABLE” before starting diagnosis according to flow table.
1. “ABS” warning lamp in combination meter 3. Data link connector (DLC) 5. To ECM, TCM, P/S control module and SDM
2. ABS hydraulic unit/control module assembly 4. ABS hydraulic unit/control module connector 6. To main fuse box
